[INCH-POUND]
A-A2679A
August 10, 1995
A-A-2769
May 1, 1991

COMMERCIAL ITEM DESCRIPTION
SAW, CIRCULAR, PNEUMATIC, PORTABLE

This Commercial Item Description is approved by the Commissioner, Federal Supply Service, General Services Administration, for the use of all Federal agencies.

1. Scope. This commercial item description covers 12-inch, portable, pneumatic circular saws primarily intended for cutting steel, stone, masonry, ceramics, plastics, and other ferrous and nonferrous materials.

2. Salient Characteristics.

2.3 Design. Circular saws applied in accordance with this description shall be of the manufacturer�s current design, be similar to Figure 1 and shall be in accordance with Table I. The saw shall be of the 12 inch size with a safety lock-off throttle. The saw shall operate properly at pressures between 80-100 psig.

Table I

National Stock Number

Specified Torque
ft. � lbs.
(min.)

Speed at Specified Torque
RPM
(min.)

Speed at
No Load
RPM
(max.)

Air Consumption
scfm/hp
(max.)

90^O
Depth
of cut
inches
(min.)

45^ODepth of
Cut
inches
(min.)

5130-00-239-5813

1500

2400

3-7/8

2-3/4

2.2 Motor: The motor shall be the rotary-vane type.

Beneficial comments, recommendations, additions, deletions, clarifications, etc., and any other data which may improve this document should be sent to: General Services Administration, Federal Supply Service, Tools and Appliances Commodity Center (6FETE-CO), Washington DC 20406.
